Manufacturer: Manufactured by Kuibyshev(Russia)

Nominal weight of falling parts, kg: 150

Energy of impact, Kj: 2,5

The greatest number of impacts in a minute: 190

Ram axis-to-frame distance, mm: 350

Working zone daylight, mm: 370

Die impression size, mm: 200 x 85

Lower die impression-to-floor distance, mm: 800

Optimum workpiece cross-sectional dimensions, mm:
– square 120 x 120
– rounded 135

Main electric motor power, kW: 10

Weight of a hammer with an anvil-block: 4430kg

Hammer dimensions: 2290 x 1040 x 207mm
