YOM 1990
Weight of the falling parts: 196 kg
Number of strokes per min: 210
Effective kinetic energy of falling part by stroke: 330 kg/m
Distance from ram axis-to-frame: 340 mm
Anvil height above the floor: 750 mm
Stroke run: 460 mm
Striking area: 75×190 mm
Motor: 15kW
Overall dimensions mm: -Length: 930 mm -Width: 1860 mm -Height: 2160 mm
Weight of the hammer: 3450 kg
Weight of anwill 1650 kg
