AIR FORGING HAMMER C FRAME STANKO VORONEZ MA 417

1.jpg 2.jpg 3.jpg 4.jpg
Contact person
MachineSpot® Support
Phone
+386 (0)2 292 76 99
Email
info@machinespot.com
Call Call Contact Mail Mail Enquiry Print Print Print Used machine watch Used machine watch Watchlist
AIR FORGING HAMMER C FRAME STANKO VORONEZ MA 417 DescriptionAIR FORGING HAMMER C FRAME STANKO VORONEZ MA 417 DescriptionDescription

YOM 1975
Nominal weight of the falling parts: 750 kg
Max. number of blows per minute: 105
Kinetic energy: 1900 kg
Distance from an axis of the slider up to bed: 750 mm
Cylinder diameter: 600 mm
Diameter of the plunger: 630 mm
Max. headstock travel: 835 mm
Dimensions:
-Left-to-right: 3940 mm
-Front-to-back: 1430 mm
Height above floor level: 3260 mm
Weight:
-With an anvil-block: 25600 kg
-Without an anvil-block: 16600 kg

Item Id #   343
Manufacturer   Stanko
Model / Type   Voronez MA 417
Year of manufacture   1975
Machine available from   immediately
Machine condition   good
Machine location   Lithuania
Payment terms   100% payment prior to collection
