Find Machinery Metalworking Machinery Milling Machines HORIZONTAL FORGING MACHINE (UPSETTER) STANKO RYAZAN V 1136

HORIZONTAL FORGING MACHINE (UPSETTER) STANKO RYAZAN V 1136

1.jpg 2.jpg 3.jpg 4.jpg
Contact person
MachineSpot® Support
Phone
Email
Call Call Contact Mail Mail Enquiry Print Print Print Used machine watch Used machine watch Watchlist
HORIZONTAL FORGING MACHINE (UPSETTER) STANKO RYAZAN V 1136 DescriptionHORIZONTAL FORGING MACHINE (UPSETTER) STANKO RYAZAN V 1136 DescriptionDescription

Manufacturer: Manufactured by Tyazhpressmash (Russia)

Year of manufacture: 1985

Capacity: 400ton

Movable die stroke: 125mm

Max. upsetting ram stroke: 290mm

Upsetting ram work stroke: 190mm

Upsetting ram return stroke with closed dies: 60mm

Distance between upsetting ram and dies stroke forward: 100mm

Number of ram strokes per minute: 50

Die dimensions: 450 x 160 x 480mm

Electric motor power: 21kW

Machine dimensions: 4330 x 3150 x 1860mm

Machine weight: 36000kg

Item Id #   345
Manufacturer   Tyazhpressmash
Model / Type   Ryazan V 1136
Year of manufacture   1985
Machine available from   immediately
Machine condition   good
Machine location   Lithuania
Payment terms   100% payment prior to collection
