Manufacturer: Kalinin plant (Russia)

YOM: 1985

Nominal weight of falling parts, kg: 1000

Energy of impact, Kj: 30

The greatest number of impacts in a minute: 103

Ram axis-to-frame distance, mm: 800

Working zone daylight, mm: 750

Die impression size, mm: 360 x 140

Lower die impression-to-floor distance, mm: 750

Optimum workpiece cross-sectional dimensions, mm:
– square 160
– rounded 180

Main electric motor power, kW: 75

Machine dimensions, mm: 4400 x 1780 x 3570

Weight of a hammer, kg: 23000

Weight of a an anvil-block, kg: 14000
