YOM 1978
Nominal force, 630 ton.
Nominal working pressure, MPa 20
Max.stroke of hydraulic ram of main cylinder, 1000mm
Variable Speed of hydraulic ram main cylinder, mm/sec
At idle stroke 20—30
At working stroke 1,2—2,5
Ar return stroke 30—45
Distance Between Hydraulic Ram Face And stop transverse beam, mm 500-4000
Movement Speed of stop transverse beam, mm/sec. 70
Max.diameter of workpiece, mm 1600
Total power, kW 18,5
Overall Dimension, mm:
Length 11 000
Width 3000
Height 3280
Height Above the floor, mm 2865
Mass , kg 29 450
