Manufacturer: Maschinenfabrik Weingerten AG

YOM: 1978

Made in: Germany

Nominal capacity: 2300 tons

Max. capacity: 3600 tons

Course stroke:
-Max.: 600 mm
-Min.: 280 mm

Min. stroke with max. energy: 570 mm

Screw diameter: 480 mm

Table size: 1000×1150 mm

Ram size: 1000×1100 mm

Distance between table and ram:
-Ram up: 1500 mm
-Ram down: 900 mm

Distance below guides: 1300 mm

Distance between guides: 820 mm

Height above floor: 7520 mm

Press weight: 135 tons
