Manufactured by: Ryazan plant (Russia)

Max.working length: 2800mm

Max. work piece diameter: 630 mm

Max. work piece diameter above support: 350mm

Max. work piece length: 2800mm

Max. work piece weight between centers: 2000kg

Spindle bore diameter: 65mm

Spindle speed range(rpm): 12,5…1600

Thread:
– Metric, mm: 1…192
– Inch, (thread/inch): 24…0,25
– Module, module: 0,5…48
– Pitch, diametric pitch: 96…1

Power required: 15kW

Machine dimensions: 4950 x 1590 x 1420mm

Machine weight: 5560kg
