Manufacturer: Stanko

Year of manufacture app.: 1985

Max. work piece diameter: 200mm

Module: 4

Table diameter: 200mm

Spindle speed: 63…400rpm

Bore taper of the milling carriage (Morse): 4

Max. tilt angle of the cut wheels’ teeth, gr.: +-/ 60

Distance between the axes of the table and the cutter: 145…365mm

Distance between the table surface and the cutter: 45…180mm

Max. dimensions of hob mounted: 125 x 125mm
Main electric motor power: 4kW

Machine overall dimensions: 2000 x 1300 x 2040mm

Machine weight: 4350kg
