Manufacturer: Stanko
YOM: 1988
Conditioned Drilling capacity:
– In steel: 50 mm
– In cast iron: 63 mm
Spindle overhang:
– Max 1600 mm
– Min 375 mm
Distance from spindle nose to working surface of table:
– Max. 1 600 mm
– Min. 450 mm
Spindle taper: MT5
Max spindle travel: 400 mm
Spindle speed range: 18-2000 rpm
Number of feedings: 24
Range of feedings: 0.045-50 mm/rev
Main motor power: 5.5 kW
Dimension: 2850x1030x3430 mm
Weight: 4 700 kg
